Product Description

The FLYFLOW 304 Stainless Steel Micro Quick-Twist Elbow Air Hose Connector is a specialized pneumatic component. Constructed from 304 stainless steel, it offers exceptional durability, corrosion resistance, and reliability. Its micro elbow design enables quick and secure connection of a 0.16″ (4mm) pneumatic hose and an M3 male threaded component, making it suitable for a wide range of micro industrial applications where compact and efficient 90° air distribution is essential, especially in robotics and 3D printing sectors.

Specifications

• Brand: FLYFLOW
• Product Name: 304 Stainless Steel Micro Quick-Twist Elbow Air Hose Connector
• Model: PL4-M3
• Material: 304 Stainless Steel
• Hose Size: 0.16″ (4mm) OD
• Thread Size: M3 Male Thread
• Type: Micro Quick-Twist Elbow Connector
• Quantity: 1 Piece

Features

• Durability: 304 stainless steel construction withstands micro pneumatic system demands, resisting wear and ensuring long-term reliability.
• Compact Design: Small size makes it ideal for space-constrained micro pneumatic setups in robotics and 3D printing.
• 90° Directional Change: Facilitates air routing at a right angle, enabling flexible pneumatic piping designs in compact setups.
• Quick-Twist Assembly: Enables fast and secure connection of the hose, reducing installation time in micro industrial operations.
• Corrosion Resistance: 304 stainless steel material provides excellent corrosion resistance, making it suitable for use in various environmental conditions.

Application

Ideal for use in micro industrial pneumatic systems across sectors like robotics and 3D printing. It can be used to connect a 0.16″ (4mm) pneumatic hose to an M3 threaded component at a 90° angle, enabling efficient air transmission in micro manufacturing, robotic operations, and 3D printing processes.

Installation Guidelines

1. Ensure the end of the pneumatic hose (0.16″ / 4mm OD) is cut cleanly and free of debris.
2. Insert the hose into the quick-twist port of the elbow connector and twist the locking mechanism clockwise until it is securely tightened, ensuring a firm fit.
3. Thread the M3 male end of the connector onto the corresponding female threaded component in the pneumatic system, tightening it securely with an appropriate tool to prevent air leakage.
4. Test the pneumatic system after installation to ensure proper air flow and no leakage.
