Product Description

The FLYFLOW 304 Stainless Steel Micro Quick-Twist Three-Way Air Hose Connector is a specialized pneumatic component. Constructed from 304 stainless steel, it offers exceptional durability, corrosion resistance, and reliability. Its micro three-way design enables quick and secure connection of two 0.24″ (6mm) pneumatic hoses and one M6 male threaded component, making it suitable for a wide range of micro industrial applications where compact and efficient three-way air distribution is essential, especially in robotics and 3D printing sectors.

Specifications

• Brand: FLYFLOW
• Product Name: 304 Stainless Steel Micro Quick-Twist Three-Way Air Hose Connector
• Model: PB6-M6
• Material: 304 Stainless Steel
• Hose Sizes: 0.24″ (6mm) OD (two ports)
• Thread Size: M6 Male Thread (one port)
• Type: Micro Quick-Twist Three-Way Connector
• Quantity: 1 Piece

Features

• Durability: 304 stainless steel construction withstands micro pneumatic system demands, resisting wear and ensuring long-term reliability.
• Compact Design: Small size makes it ideal for space-constrained micro pneumatic setups in robotics and 3D printing.
• Quick-Twist Assembly: Enables fast and secure connection of hoses, reducing installation time in micro industrial operations.
• Corrosion Resistance: 304 stainless steel material provides excellent corrosion resistance, making it suitable for use in various environmental conditions.
• Versatility: Applicable for various micro industrial pneumatic applications, including robotics and 3D printing, where compact three-way connections are required.

Application

Ideal for use in micro industrial pneumatic systems across sectors like robotics and 3D printing. It can be used to connect two 0.24″ (6mm) pneumatic hoses and one M6 threaded component in a three-way configuration, enabling efficient air transmission in micro manufacturing, robotic operations, and 3D printing processes.

Installation Guidelines

1. Ensure the ends of the pneumatic hoses (0.24″ / 6mm OD) are cut cleanly and free of debris.
2. Insert each hose into the corresponding quick-twist port of the three-way connector and twist the locking mechanism clockwise until it is securely tightened, ensuring a firm fit.
3. Thread the M6 male end of the connector onto the corresponding female threaded component in the pneumatic system, tightening it securely with an appropriate tool to prevent air leakage.
4. Test the pneumatic system after installation to ensure proper air flow and no leakage.
