Product Description

The ZHENGMI Quick Plug Air Hose Connector with Internal Thread Straight is a specialized pneumatic component. Constructed from brass and plastic, it offers excellent durability, corrosion resistance, and reliable performance. Its design enables quick and secure connection of a 0.31″ (8mm) pneumatic hose to a 1/8″ internally threaded (R/PT/ZG thread) component, making it suitable for a wide range of industrial applications where reliable and efficient straight connections are essential.

Specifications

• Brand: ZHENGMI
• Product Name: Quick Plug Air Hose Connector with Internal Thread Straight
• Model: PCF 8-01
• Material: Brass + Plastic
• Hose Size: 0.31″ (8mm) OD
• Thread Size: 1/8″ Internal Thread (R/PT/ZG thread)
• Type: Straight Connector
• Quantity: 1 Piece

Features

• Durability: Brass construction withstands pneumatic system demands, resisting wear and ensuring long-term reliability, while plastic components add functional versatility.
• Quick Plug-In Connection: Enables fast assembly of the pneumatic hose, reducing installation time in industrial operations.
• Straight Layout: Facilitates linear air flow, enabling efficient pneumatic piping designs for straight air transmission.
• Corrosion Resistance: Brass material provides good corrosion resistance, making it suitable for use in various environmental conditions.
• Versatility: Applicable for various industrial pneumatic applications, providing reliable air transmission between hoses and internally threaded components.

Application

Ideal for use in industrial pneumatic systems across multiple sectors where reliable straight connections between hoses and internally threaded components are required. It can be used in various pneumatic systems in industries such as manufacturing, assembly, and automation, enabling efficient air transmission between a 0.31″ (8mm) hose and a 1/8″ internally threaded component.

Installation Guidelines

1. Ensure the end of the pneumatic hose (0.31″ / 8mm OD) is cut cleanly and free of debris.
2. Push the hose firmly into the quick plug port of the straight connector until it clicks into place, ensuring a secure fit.
3. Thread the internal threaded part of the connector onto the corresponding external threaded component in the pneumatic system, tightening it securely to prevent air leakage.
4. Test the pneumatic system after installation to ensure proper air flow and no leakage.
