Product Description
The AIRAC PG Series Reducing Straight Tube Connector is a specialized pneumatic component. Constructed from brass, it offers excellent durability and corrosion resistance. Its reducing straight design enables quick and secure connection of a 0.47″ (12mm) hose and a 0.39″ (10mm) hose, making it suitable for a wide range of industrial applications where reliable and efficient reducing straight connections are essential, especially in environments where copper is prohibited.
Specifications
- Brand: AIRAC
- Product Name: PG Series Reducing Straight Tube Connector
- Model: PG12-10
- Material: Brass
- Hose Sizes: 0.47″ (12mm) OD and 0.39″ (10mm) OD
- Type: Reducing Straight Tube Connector
- Quantity: 1 Piece
Features
- Durability: Brass construction withstands pneumatic system demands, resisting wear and ensuring long-term reliability.
- Reducing Design: Enables connection of hoses with different diameters (12mm and 10mm), facilitating flexible pneumatic piping designs.
- Copper-Free: Suitable for environments where copper is prohibited, expanding application versatility.
- Quick Plug-In Connection: Enables fast assembly of hoses, reducing installation time in industrial operations.
- Excellent Flow Performance: Designed to ensure optimal air flow, matching the flow capacity of the hose inner diameter.
Application
Ideal for use in industrial pneumatic systems across multiple sectors where reducing straight connections between hoses of different diameters are required, including environments where copper is prohibited. It can be used in various pneumatic systems in industries such as manufacturing, assembly, and automation, enabling efficient air transmission between hoses of 12mm and 10mm diameters.
Installation Guidelines
- Ensure the ends of the pneumatic hoses (0.47″ / 12mm OD and 0.39″ / 10mm OD) are cut cleanly and free of debris.
- Push each hose firmly into the corresponding quick plug port of the reducing straight connector until they click into place, ensuring secure fits.
- Test the pneumatic system after installation to ensure proper air flow and no leakage.
