Product Characteristics

• Durability: Made from 304 stainless steel, the elbow quick connector is highly resistant to corrosion, wear, and suitable for long-term use in pneumatic applications.
• Connection Efficiency: Quick-insert mechanism allows for instant tube insertion and removal, saving time during pneumatic system assembly and maintenance.
• Flow Direction Control: 90-degree elbow design enables smooth directional changes in air flow, suitable for routing pneumatic tubes around obstacles.

How to Use

1. Ensure the tube outer diameter is 6mm and the threaded port is M5.
2. Push the 6mm OD tube firmly into the connector’s tube port until it clicks into place, indicating a secure connection.
3. Apply thread sealant (if needed) to the M5 male thread and screw the connector onto the threaded port by hand first, then tighten with a wrench (avoid over-tightening to prevent thread damage).
4. To disconnect the tube, press the release collar and pull the tube out. Inspect the connection for air leaks before operating the system, and regularly check for any signs of wear or damage.

Maintenance Tips

• Periodically inspect the connector for signs of wear, corrosion, or air leaks.
• Ensure the tube and threaded connections remain clean and free of debris to maintain optimal performance.
• Lubricate the release collar (if applicable) to ensure smooth tube disconnection.
• Replace the connector immediately if any damage or leakage is detected to prevent pneumatic system issues.
